 Industrial 8 Ports Fast Ethernet Switch

Industrial 8 Ports Fast Ethernet Switch

UTP7208E-A1



  •  $row.goods_name
  •  $row.goods_name
  •  $row.goods_name
  • Description
  • Specifications
  • Dimensions
  • Applications
  • Package
  • Download
  • Related Video

The un-managed industrial ethernet switch provides one uplink ethernet port and one uplink optical port (1000Mbps),eight 100Mbps downlink ethernet ports. This product is designed for high definition IP camera network access, which supports one key CCTV model, can achieve VLAN, restrain the Network storm, protect the information security, prevent the virus spread and Ethernet attack; it also integrates optical interface to achieve the perfect performance which blend with fiber optical transceivers and network switches, to solve the problem of long-distance transmission. The product could be used in network security video surveillance, network project etc.


Model

UTP7208E-A1

Downstream Ports

8* 10/100Base-TX

Uplink Ports

1*1000Mbps SFP Port and 1*10/100/1000Base-T

Network Standard

IEEE802.3 IEEE802.3uIEEE802.3abIEEE802.3zEEE802.3 X

Switch Capacity

5.6Gbps

Throughput

4Mpps

Switch Processing Scheme

Store and Forward

Memory Buffer

1M

MAC Table

8K

Lightning protection

6KV    ExecuteIEC61000-4-5

ESD

6KV     Contact discharge

8KV       Air discharge

ExecuteIEC61000-4-2

Power Supply

DC 12V~24V

Power Dissipation

5W

Work temperature

-40~75

Storage temperature

-40~85

Humidity(Non-condensin)

5%-95%

DimensionL×W×H

159mm×110mm×46mm

Weight

530g

Regulator

CEFCCROHS


Designation

Quantity

UTP7208E-A1

1

Power  Adapter

1

Hanger

2

Guide hangers

1

User Manual

1
