 4 Ports Full Gigabit PoE Switch

4 Ports Full Gigabit PoE Switch

UTP3-GSW04-TP60
  •  $row.goods_name
  •  $row.goods_name
  •  $row.goods_name
  • Description
  • Specifications
  • Dimensions
  • Applications
  • Package
  • Download

The 4 Ports Full Gigabit PoE Switch is specially designed for the application of high definition network security surveillance system. The PoE switch provides 4 Gigabit downlink PoE ports support 802.3at and dual Gigabit uplink ports.the total PoE power output is up to 60 watts. It’s widely used in survelliance monitor and Ethernet network solution.



Model

UTP3-GSW04-TP60

Downstream Ports

4* 10/100/1000Base-T (PoE)

Uplink Ports

2*10/100/1000Base-T

Network Standard

IEEE802.3 IEEE802.3uIEEE802.3abEEE802.3 X

Switch Capacity

12Gbps

Throughput

8.93Mpps

Switch Processing Scheme

Store and Forward

Memory Buffer

1M

MAC Table

2K

PoE Standard

802.3af/at(PSE)

PsE  Type

End-span

Power Pin Assignment

1/2(+)3/6(-)

PoE Power Output

54V DC , 30 watts max

PoE Budge

60 watts max

Lightning protection

6KV    ExecuteIEC61000-4-5

ESD

6KV     Contact discharge

8KV       Air discharge

ExecuteIEC61000-4-2

Power Supply

DC 48V~57V

Power Dissipation

5W

Work temperature

-10~45

Storage temperature

-40~85

Humidity(Non-condensin)

5%-95%

DimensionL×W×H

135mm×86mm×27mm

Weight

343g

Regulator

CEFCCROHS










Designation

Quantity

UTP3-GSW04-TP60

1

Power  Adapter

1

Accessory

1

User Manual

1
