 5-Port Unmanaged Gigabit Switch

5-Port Unmanaged Gigabit Switch

SG5-M
  •  $row.goods_name
  •  $row.goods_name
  •  $row.goods_name
  • Description
  • Specifications
  • Dimensions
  • Applications
  • Package
  • Download
  • Related Video

The unmanaged gigabit switch is specially designed for HD video surveillance and network engineering, providing 4*10/100/1000Mbps RJ45 ports and 1*10/100/1000Mbps Uplink RJ45 port. The switch supports three operating modes (Default, VLAN, CCTV). Under default mode, the switch supports detection for switching loop, and reminds you to check the loop-occurred port in real time through alarming LED indicator.

4*10/100/1000Mbps RJ45 ports + 1*10/100/1000Mbps Uplink RJ45 port.
IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3x.
Three operating modes (Default, VLAN, CCTV).
Loop detection: loop fault, LED alarm prompts the user to check the loop port in real time
Excellent performance of anti-interference, 6KV surge immunity & 8KV ESD protection.
Plug and play.

Model

SG5-M

Downlink Ports

5*10/100/1000Base-TX ports

Network Standard

IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3X

Switch Capacity

10Gbps

Throughput

7.24Mpps

Switch Processing Scheme

Store and Forward

Memory Buffer

1M

MAC Table

1K

Jumbo Frame

2048bytes

One-key Smart

Default: Support detection for switching loop. All port can be communicated freely.

VLAN: Port 1-3 are isolated respectively, but can communicate with Port 4-5.

CCTV: The rates of Port 1-5 are limited to 100M, but with transmission distance of 160 meters.

Lightning Protection

6KV Execute: IEC61000-4-5

ESD

6KV Contact discharge

16KV Air discharge

Execute:  IEC61000-4-2

Power Supply

Desktop power adapter, DC 2.1 Jacket

Power Input

AC: 100~240V- 50~60Hz

Power Output

DC: 5V- 0.6A

Surge on Power Supply

Common mode - 6KV,  Difference mode - 4KV

Power Consumption

3W

Work Temperature

-10℃~50℃

Storage Temperature

-40℃~85℃

Humidity (Non-condensing)

10%-90%

Dimension (L*W*H)

122mm*92mm*25mm

Weight

1kg

Certification

CE, FCC, ROHS


Item

Quantity

SG5-M

1

Power Adapter

1

User Manual

1
