Combining with algorithm of advanced infrared temperature measurement and adaptive multi-sensor for cooperative environmental, intelligent doorbell TS1206 achieves infrared temperature measurement, data display of body temperature, voice alarm, etc. It can read body temp measurement with fast-speed, long-distance and accurate. And it is applied to the temp measurement scene with less people and achieves single screening one by one.


ADVANTAGES

• Built-in non-contact infrared temp measurement module to ensure accurate temp measurement.

• Temperature measurement range is from 35 ℃ to 42 ℃ with accuracy ± 0.3 ℃.

• Self-service temperature measurement to avoid cross infection.

• Alarm when the temperature of the person being detected is abnormal.

• Advanced aluminum alloy metal housing and durable.

• Support wall and pole installation.

UTEPO, ts1501

Item

Specification

CPU

ARM Cortex-m

Temperature Display

LED digital display

Sensor

Thermal image infrared temperature sensor

Temperature Measurement

Rang: 35°C ~42°C , accuracy: ±0.3°C

Detection Distance

30~60cm

Respond Time

1~3s

Alarm Method

Warning ring,Warning voice (70db)+ LED red indicator

Power Consumption

≤5W

Operating Temperature

15°C ~35°C(indoor)

Operating humidity

0%-85% RH(Non-condensing)

Dimensions(L×W×H)

45mm×105mm×193mm

Weight

542g

Item

Model

QTY

Note

Machine body

TS1206

1

Bracket

/

1

Adapter

/

1

5V1A AC-DC power adapter

Charging line

/

1

1 meter, USB Type-A to USB Type-C charge wire

User manual

/

1
