 20-Port Gigabit PoE+ 4-Port Gigabit Combo 4-Port 10G SFP+ L3 Managed Ethernet Switch

20-Port Gigabit PoE+ 4-Port Gigabit Combo 4-Port 10G SFP+ L3 Managed Ethernet Switch

UTP5628S-PSB-L3
  •  $row.goods_name
  •  $row.goods_name
  • Description
  • Specifications
  • Dimensions
  • Applications
  • Package
  • Download
  • Related Video
  • Related Product


OVERVIEW

This series of switches is enterprise-class stackable routing switch with fixed, built-in 10GbE uplink ports. It has great performance on availability, scalability, security and energy efficiency. This fully managed switch provides high switching capacity, supports wire-speed L2/L3 forwarding and high routing performance for IPv4 and IPv6 protocols. Thanks to the VSF (Virtual Switch Framework), the management work for the network administrator is simplified. Multiple switches can be virtualized into one logical device, achieving the sharing of information and data tables between different switches, which provides more reliability. It delivers high-performance, hardware-based on IP routing. RIP, OSPF, and BGP provide dynamic routing by exchanging routing information with other Layer 3 switches and routers. It is ideal for aggregation or access layer for campus, enterprise, government and internet service provider networks.


FEATURES AND HIGHLIGHTS

Abundant Interfaces

UTP5628S-L3(V2): 24*10/100/1000 Base-T RJ-45 ports

UTP5628S-PSB-L3: 20*10/100/1000 Base-T PoE+ RJ-45 ports + 4*1000Mbps Combo (RJ-45/SFP)

UTP5652S-L3(V2): 48*10/100/1000 Base-T RJ-45 ports

UTP5652S-PSB-L3: 48*10/100/1000 Base-T PoE+ RJ-45 ports

• 4*10GBase-X SFP+ ports

• 1*RJ-45 Ethernet Management port

• 1*Console port

• 1*Reset port

• 1*USB2.0 interface


Layer 3 Features

• RIPv1/v2

• OSPFv2/v3

• BGP4/BGP4+

• VRRP

• IGMP

• IPv6 Support


Layer 2 Features

• 802.1Q VLAN

• QoS

• STP/RSTP/MSTP

• ERPS

• IGMP snooping

• LACP

• LLDP


VSF (Virtual Switch Framework)

Virtual Switch Framework can virtualize multiple switches into one logical device, achieving the sharing of information and data tables between different switches.



l3 switch


This series of switches is an enterprise-class stackable routing switch with fixed, built-in 10GbE uplink ports. It has great performance on availability, scalability, security, and energy efficiency. This fully managed switch provides high switching capacity, supports wire-speed L2/L3 forwarding, and high routing performance for IPv4 and IPv6 protocols.


Thanks to the VSF (Virtual Switch Framework), the management work for the network administrator is simplified. Multiple switches can be virtualized into one logical device, achieving the sharing of information and data tables between different switches, which provides more reliability. It delivers high-performance and hardware based on IP routing. RIP, OSPF, and BGP provide dynamic routing by exchanging routing information with other Layer 3 switches and routers. It is ideal for aggregation or access layers for campus, enterprise, government, and internet service provider networks.


UTEPO switch features



● High Port Density with Flexible Expansion Capability

This series of switches are high port density, providing 24/48 Gigabit downlink ports and 4 10GbE SFP+ ports. They support wire-speed forwarding with powerful forwarding capability. At the same time, the uplink 10GbE ports can provide flexible expansion capability and can be used as aggregation switches in the system to address different needs, such as storage, backup, and long-distance transmission. What’s more, the switches provide 1*USB 2.0 interfaces to support local updates for software, avoiding device crashes caused by power failure during web upgrades.


PoE switch



● Abundant L2/L3 Management Function

Support static routing, RIP, OSPF, IPv6, QoS, SNMP, VLAN, multicast, etc.


l3 managed switch



>>> RIP and OSPF

With the dynamic routing function of RIP (Routing Information Protocol) and OSPF (Open Shortest Path First), the switch solves the routing problem of large and medium complex networks after subnet subdivision and simplifies network configuration.

Managed Switch



>>> PBR

With the switch, customers could achieve Policy-based Route (PBR) easily, which plays an important role when they need a multi-exit application and provides application experience for the customer.


UTEPO Managed Switch



>>> Abundant IPv6/IPv4

Support IPv6/IPv4 switching and routing based on hardware for maximum performance. With the increased number of network devices growing, the need for larger addressing and higher security becomes critical. It will be the right product to meet this requirement.


ipv6 switch



● VSF Stackable Design (Virtual Switch Framework)

The series supports VSF stacking technology which virtualizes multiple switches into a single large one, achieving the sharing of information and data tables between different switches. The performance and port density of the virtualized device is greatly enlarged by times under VSF. VSF also simplifies management work for the network administrator and provides more reliability.


Stackable Managed Switch



● Unparalleled Manageability

Support rich management interfaces, such as Console, RJ-45 Ethernet port, USB interface, SNMPv1/V2/v3, CLI, TELNET and FTP configuration, etc., to make device management more convenient, and support SSHv1/v2, SSL and other encryption methods, making management more secure.


UTEPO Managed Switch



UTEPO Switch Aoolication



UTEPO Switch diagram


UTEPO Switch Specification



Non-PoE


UTP5628S-L3

● 24*GE + 4*10GE SFP+

● L3 management

● VSF stacking

● IPv6



UTP5652S-L3

● 48*GE + 4*10GE SFP+

● L3 management

● VSF  stacking

● IPv6



PoE


UTP5628S-PSB-L3

● 20*GE PoE + 4*GE Combo (RJ-45/SFP) + 4*10GE SFP+

● IEEE 802.3af/at

● PoE budget: 370W

● L3 management

● VSF stacking

● IPv6


UTP5652S-PSB-L3

● 48*GE PoE + 4*10GE SFP+

● IEEE 802.3af/at

● PoE budget: 740W

● L3 management

● VSF stacking

● IPv6



Full Fiber


UTP5628TFS-L3

● 16*GE SFP + 8*GE Combo (RJ-45/SFP) + 4*10GE SFP+

● AC/DC redundant power supply

● L3 management

● VSF stacking

● IPv6

Items

UTP5628S-L3(V2)

UTP5628S-PSB-L3

Hardware Specifications

Downlink Port

24*10/100/1000BASE-T RJ-45 ports

20*10/100/1000BASE-T PoE+ RJ-45 ports

4*1000Mbps Combo (RJ-45/SFP)

Uplink Port

4*1/10GBASE-X SFP+

Management Port

1*RJ-45 Ethernet management port

1*Console port

1*Reset port

1*USB2.0 interface

Cable

Cat5 or better

Dimensions (W*D*H)

440mm*240mm*44mm

440mm*320mm*44mm

Single Package Weight

3.45kg

5.4kg

Single Package Dimensions

530mm*322mm*98mm

530mm*480mm*110mm

Power Supply

AC: 100~240VAC, 50~60Hz

AC: 100~240VAC, 50~60Hz

Power Consumption

<30W(Full load)

<471W(Full load, include PoE)

Material

Metal shell

Switch Property

Forwarding Modes

Store and Forward

Switching Capacity

128Gbps, non-blocking

Packet Forwarding Rate

95Mpps

Jumbo frame

10K

MAC Table

16K, supported auto learning

ARP Table

4K

Routing Table

1K

ACL Table

1K

PoE

PoE Standard

N/A

IEEE 802.3af/at

PoE Budget

N/A

30W max for each port, 370W max for whole switch

Environments

Operating

Temperature: 0℃~50℃

Relative Humidity: 10%~90% (Non-condensation)

Storage

Temperature: -40℃~70℃

Relative Humidity: 10%~95% (Non-condensation)

ESD

Contact Discharge: ±8kV, Air Discharge: ±15kV

Surge

±6kV

Software Architecture

Main Features

L1, L2 Features

L1 Standard

IEEE 802.3(10BASE-T), IEEE 802.3u(100BASE-TX), IEEE 802.3z(1000BASE-X), IEEE 802.3ab(1000BASE-T), IEEE 802.3ae(10GBase), IEEE 802.3x, IEEE 802.3ak(10GBASE-CX4)

LLDP & LACP

Port loopback detection

LLDP and LLDP-MED

ULDP

802.3ad LACP, max 128 group trunks with max 8 ports for each trunk(UTP5652S-PSB-L3 supports max 64 group trunks with max 8 ports for each trunk )

LACP load balance

ERPS (G.8032)

Mirroring

N:1 Port Mirroring

RSPAN

Spanning Tree

IEEE 802.1D(STP)

IEEE 802.1w(RSTP)

IEEE 802.1s(MSTP)

Root Guard

BPDU Guard

BPDU Tunnel

VLAN

802.1Q, 4K VLAN

MAC VLAN, Voice VLAN, PVLAN, Protocol VLAN, Multicast VLAN

QinQ, Flexible QinQ

GVRP

N:1 VLAN Translation

Broadcast / Multicast / Unicast Storm Control

IGMP

IGMP v1/v2/v3 Snooping and L2 Query

ND Snooping

MLDv1/v2 Snooping

Security

Port Security

Port Congure

Flow Control: HOL, IEEE 802.3x

Bandwidth Control

L3 Features

IP Routing

Static Routing, RIPv1/v2, OSPFv2, BGP4, OSPFv3, BGP4+

OSPF multiple processes

LPM Routing

Policy-based routing (PBR) for IPv4 and IPv6

VRRP

URPF

ECMP

BFD

IGMP

IGMP v1/v2/v3, IGMP Proxy

Static Multicast Route

Multicast Receive Control

Illegal Multicast Source Detect

ARP

ARP Guard, Local ARP proxy, Proxy ARP, ARP Binding, Gratuitous ARP, ARP Limit

Anti ARP Cheat, Anti ARP Scan

DNS

DNS Client, DNS Relay

GRE

GRE Tunnel(UTP5652S-PSB-L3 doesn’t support)

Advanced Congure

IPv6

6to4 Tunnel, Configured Tunnel, ISATAP Tunnel, GRE Tunnel(UTP5652S-PSB-L3 doesn’t support)

ICMPv6, ND, DNSv6

IPv6 LPM Routing, IPv6 Policy-based Routing (PBR)

IPv6 VRRPv3, IPv6 URPF, IPv6 RA

RIPng, OSPFv3, BGP4+

MLD Snooping, IPv6 Multicast VLAN

MLDv1/v2, IPv6 ACL, IPv6 QoS

QoS

8 Queues

SP, WDRR, SWDRR

Traffic Classification Based on 802.1p CoS, ToS, DiffServ DSCP, ACL, port number

Traffic Policing

PRI Mark/Remark

ACL

IP ACL, MAC ACL, IP-MAC ACL, User-Defined ACL

Standard and Expanded ACL Based on source/destination IP or MAC, IP Protocol, TCP/UDP port, DSCP, ToS, IP Precedence), VLAN, Tag/Untag, CoS

Redirect and statistics

Rules can be configured to port, VLAN

Time Ranged ACL

ACL rules can be configured to port, VLAN

Security

802.1x AAA

Port, MAC-based authentication

Accounting based on time length and traffic

Guest VLAN and auto VLAN

RADIUS for IPv4 and IPv6

TACACS+ for IPv4 and IPv6

MAB

DHCPv4/v6 Traffic Monitor

DHCP Server/Client for IPv4/IPv6

DHCP Relay/Option 82

DHCP Snooping/Option 82

Traffic Monitor

sFlow Traffic Analysis

Security Network Management

CLI, WEB, Telnet, SNMPv1/v2c/v3 through IPv4 and IPv6

Syslog and external Syslog Server

HTTP SSL

SNMP MIB, SNMP TRAP

FTP/TFTP

SNTP/NTP

RMOM 1,2,3,9

Authentication by Radius/TACACS

SSH v1/v2

Dual firmware images/ Configuration files

802.3ah OAM, 802.1ag OAM

Data Center Features

VSF (Virtual Switch Framework), up to 4 stack members
